Product Description
| Chute Option Available |
12 Chute |
10 Chute |
8 Chute |
7 Chute |
6 Chute |
5 Chute |
4 Chute |
3 Chute |
2 Chute |
1 Chute |
| Chute Distribution (P+S+F) |
7+3+
2
or
7+2+
2+1 |
6+2+2
or
6+2+1+
1 |
5+2+1
or
4+2+1+
1) |
4+2+1
or
4+2+(
40+21) |
4+1+1
or
4+2+(
40+21) |
3+1+1
or
3+1+(
40+21) |
2+1+1
or
2+1+(
40+21) |
2+1
or
2+(40
+21) |
1+1
or
1+(40
+21) |
---- |
| Output (TPH) for Rice/Dal |
7 to 9 |
6 to 8 |
5 to 7 |
4 to 6 |
3.5 to 4.5 |
3 to 5 |
2 to 4 |
1.5 to 2.5 |
1 to 2 |
0.75 to 1.5 |
No of camera(F&R)
|
12+12 |
10+10 |
8+8 |
7+7 |
6+6 |
5+5 |
4+4 |
3+3 |
2+2 |
1+1 |
| Air@7.5kg/C m2 |
230 CFM |
180 CFM |
160 CFM
|
140 CFM
|
115 CFM
|
96 CFM
|
72 CFM
|
54 CFM
|
44 CFM
|
28 CFM
|
| Compressor Requirement |
50 HP
Screw |
40 HP
Screw |
35 HP
Screw |
35 HP
Screw |
30 HP
Screw |
25 HP
Screw |
20 HP
Screw |
15 HP
Screw |
10 HP
Screw |
10 HP
Screw |
| Dimension(LxWxH) feet |
16x4.
88x5.
97 |
13.83x
4.88x5.
97 |
10.87x
4.88x5.
97 |
9.73x4
.88x5.
97 |
8.59x4
.88x5.
97 |
7.46x4
.88x5.
97 |
6.33x4
.88x5.
97 |
5.19x4
.88x5.
97 |
4.1x4.
88x5.
97 |
2.92x4
.88x5.
97 |
| Cabin Dimension Feet (LxWxH) |
20x10
x8 |
18x10x
8 |
16x10x
8 |
14x10
x8 |
13x10
x8 |
12x10
x8 |
10x10
x8 |
9x10x
8 |
8x10x
8 |
7x10x
8 |
Contact Us
Discover how COMMANDOR Color Sorter Machines can transform your sorting process. Contact our sales team for more information and to schedule a demonstration.
Call or WhatsApp me @ 99943 99996.
Technical Details
Advanced CCD Camera & LED LightingThe Model 7 Chute Color Sorter incorporates a state-of-the-art CCD high-resolution camera system and LED illumination. This combination offers precise color detection, enabling the unit to differentiate between acceptable and defective materials. The LED lights increase clarity and object visibility, ensuring even minor defects are recognized. Operators benefit from enhanced inspection reliability, minimizing human error and maximizing consistency in output for large-scale sorting applications.
High-Capacity Intelligent SortingDesigned for efficiency, the Commandor Model 7 processes 3 to 7 tons of material per hour with impressive accuracy above 99%. Its 448 channels enable fast and parallel sorting. The jet air ejection system instantly removes undesired particles, maintaining a reject ratio of 6:1. This high-performance machine ensures swift, reliable sorting for continuous industrial usage, contributing to higher throughput and reduced waste for grain and seed processors.
User-Friendly Touch Screen ControlOperation is intuitive, thanks to the 10-inch full-color touch screen display. Operators can easily set parameters, monitor performance, and make adjustments with just a few taps. The customizable voltage options and simple interface make deployment straightforward for a wide array of industrial settings. Its low-noise operation (<70 dB) and robust stainless steel construction support continuous, comfortable use in busy processing plants.
FAQs of Commandor Model 7 Chute Color Sorter:
Q: How does the Commandor Model 7 Chute Color Sorter achieve a high sorting accuracy?
A: The Model 7 employs a CCD high-resolution camera system paired with LED illumination to detect even subtle color differences in grains, pulses, beans, and more. Advanced image processing software analyzes each item, and targeted jet air ejection efficiently removes off-color or defective materials, resulting in sorting accuracy exceeding 99%.
Q: What materials and applications is this color sorter suitable for?
A: This machine is ideal for sorting and grading rice, pulses, beans, grains, seeds, and plastics. Its robust stainless steel build and adaptable sorting method make it suitable for exporters, manufacturers, and suppliers within the agricultural and plastics processing industries.
Q: When and where can the Commandor Model 7 be operated?
A: The sorter operates reliably in environments with temperatures ranging from -20C to +45C. Its voltage is customizable to suit various regional requirements, and its engineered for use in industrial processing facilities or grain handling plants globally.
Q: What is the process flow of sorting on the Model 7?
A: Materials are loaded onto chutes and passed under high-resolution CCD cameras with LED lighting. The image processor detects imperfections or color deviations. When defects are identified, precise jets of air eject them from the flow, ensuring only quality product continues to the final output.
Q: How is the Commandor Model 7 controlled and monitored during operation?
A: The sorter features a 10-inch full-color touch screen interface. Operators use this to set sorting parameters, view real-time performance data, and adjust settings for different materials, making the sorting process user-friendly and highly customizable.
Q: What are the benefits of using this color sorter in a processing facility?
A: Facilities benefit from high throughput (up to 7 tons/hour), repeatable accuracy above 99%, low operational noise, minimal waste due to precise rejection, and durable construction. Its intelligent technology ensures consistent quality enhancement, reducing the need for additional manual inspection.
